Technical reference number

Voltage: AC 90 v ~ 90 v, 50 hz ~ 60 hz

Total power: 75 w

Bulb: adopting the high-power white light 75 w lamp bead Luminus companies in the United States

The control channel: 12 ch

Color wheel: 7 color + white light, adjustable speed, running water and pattern jitter effects, positive and negative rotation function

Prism: rotating speed, the direction variable

Focus: 2 meters to infinite electric adjustment

Projection Angle: 13 degrees

The stroboscopic light: 0 ~ 100% linear dimming, 1 ~ 30 times per second, high-speed electronic stroboscopic effect

Rotation Angle: horizontal (X) 0 ° ~ 540 ° with automatic error correction function, 10 bit adjust

Vertical (Y) 0 ° ~ 270 ° with automatic error correction function, 10 bit adjust

Control mode: the DMX 512 international standard signal control, voice control, automatic running, master and slave connection mode

Size: 340 * 280 * 430 mm net weight: 9.5 kg
